Original price was: $4,999.00.$3,499.00Current price is: $3,499.00.
Color: Powder Steel Blue
Model Year: 2023
| Size | S | M |
|---|---|---|
| Rider Height | 160-172 | 170-184 |
| Reach | 424 | 420 |
| Stack | 590 | 640 |
| Bar Width | 680 | 680 |
| BB Drop | 67 | 67 |
| Crank Length | 170 | 170 |
| Fork Length | 408 | 408 |
| Fork Rake | 45 | 45 |
| Front Center | 665 | 679 |
| Head Tube | 165 | 217 |
| Head Tube Angle | 70 | 70 |
| Rear Center | 440 | 440 |
| Seat Angle | 75 | 75 |
| Seat Tube | 450 | 450 |
| Seatpost Length | 350 | 350 |
| Seatpost Offset | 15 | 15 |
| Standover Height | 649 | 672 |
| Stem Length | 70 | 70 |
| Top Tube | 582 | 591 |
| Trail | 75 | 75 |
| Wheelbase | 1096 | 1110 |
| Frameset |
Frame:
257 AMP Premium Aluminium | Smoothwelded | Staggered Top Tube | Integrated Battery | Internal Cable Routing | Powder Coat Finish | Post Mount Disc | Internal Gear Hub dropouts
Fork:
257 Premium Aluminium | Fender Mounts | Flat Mount Disc | 12 x 100mm Thru-Axle
|
| E-System |
Drive Unit:
Bosch Performance Line CX
Battery Pack:
Bosch PowerTube | 625 Wh | Certified by Intertek Testing Services NA, Inc. | NYC Lithium-Ion Battery Safety Guidelines
Display:
Bosch Kiox
Drive Unit Control:
Bosch Kiox
Charger:
Bosch Compact Charger
|
| Cockpit |
Stem:
ICS MTT x Redshift Suspension Stem | Integrated Cockpit System Technology
Handlebar:
BMC LSB 01
|
| Seat |
Seatpost:
BMC LSP 02
Saddle:
Selle Royal Vivo Women’s
|
| Drivetrain |
Crankset:
Miranda Classic × Bosch | Gates CDX
Chainrings:
Gates Belt 113 CDX rings
Cassette:
Gates CDX
Cassette Size:
22 T
Chain:
Gates Belt 113 CDX
Shifters:
SHIMANO Alfine (SL-S7000) | Rapidfire Plus
Gears:
1 × 8
|
| Brakes |
Brake Levers / Calipers:
TEKTRO HD-EU818 / 817
Rotors:
TEKTRO TR25
Rotor Size (F/R):
180 / 160 mm
|
| Wheels |
Rims:
SR500
Hubs (F/R):
CL-712 | SHIMANO Alfine 8
Tires:
Pirelli Angel GT | 37 mm
|
| Additional Information |
Tire Clearance:
42 mm measured tire
Weight without Pedals:
21.9 kg | Size M
ASTM Classification:
Level 2
System Weight Limit:
120 kg
|
| Size — What's my size? | S, M |
|---|
