Original price was: $1,599.00.$1,119.00Current price is: $1,119.00.
Shimano Nexus 8
Premium Fenders with Integrated Rear Rack
Kickstand
| Size | S | M | L | XL |
|---|---|---|---|---|
| Rider Height | <168 | 168-180 | 178-190 | >190 |
| Reach | 400 | 415 | 425 | 440 |
| Stack | 560 | 590 | 620 | 650 |
| Bar Width | 600 | 600 | 600 | 600 |
| BB Drop | 67 | 67 | 67 | 67 |
| Crank Length | 170 | 170 | 175 | 175 |
| Fork Length | 408 | 408 | 408 | 408 |
| Fork Rake | 45 | 45 | 45 | 45 |
| Front Center | 631 | 657 | 677 | 703 |
| Head Tube | 133 | 165 | 197 | 229 |
| Head Tube Angle | 70 | 70 | 70 | 70 |
| Rear Center | 440 | 440 | 440 | 440 |
| Seat Angle | 74 | 74 | 74 | 74 |
| Seat Tube | 480 | 510 | 540 | 555 |
| Seatpost Length | 350 | 350 | 350 | 350 |
| Seatpost Offset | 15 | 15 | 15 | 15 |
| Standover Height | 760 | 790 | 819 | 838 |
| Stem Angle | ±8 | ±8 | ±8 | ±8 |
| Stem Length | 90 | 90 | 100 | 100 |
| Top Tube | 560 | 584 | 603 | 626 |
| Trail | 75 | 75 | 75 | 75 |
| Wheelbase | 1062 | 1088 | 1109 | 1135 |
| Frameset |
Frame:
257 Premium Aluminium | Smoothwelded | Powder Coat Finish | Internal Cable Routing | Flat Mount Disc | Internal Gear Hub dropouts
Fork:
257 Premium Aluminium | Fender Mounts | Flat Mount Disc | 12 x 100mm Thru-Axle
|
| Cockpit |
Stem:
BMC RSM 01
Handlebar:
BMC LSB 03
|
| Seat |
Seatpost:
BMC LSP 02
Saddle:
Selle Royal Vivo
|
| Drivetrain |
Crankset:
Gates S150 CDN
Chainrings:
Gates Belt 120 CDXrings
Cassette:
Gates SureFit 3-LOBE Unified CDX2
Cassette Size:
24T
Chain:
Gates Belt 120 CDX
Shifters:
SHIMANO Alfine (SL-S7000) | Rapidfire Plus
Gears:
1 x 8
Bottom Bracket:
BSA Threaded Bottom Bracket
|
| Brakes |
Brake Levers / Calipers:
SHIMANO MT200 Levers | BR-U300 Calipers
Rotors:
SHIMANO RT10 Rotors
Rotor Size (F/R):
180 / 180mm
|
| Wheels |
Rims:
PFR300
Hubs (F/R):
CL-712 | SHIMANO Nexus 8
Tires:
Pirelli Angel GT | 37mm
|
| Additional Information |
Tire Clearance:
42mm measured tire
ASTM Classification:
Level 2
System Weight Limit:
120kg
|
| Size — What's my size? | S, M |
|---|
