Original price was: $1,499.00.$1,049.00Current price is: $1,049.00.
SHIMANO Deore 11 spd
Premium Fenders with Integrated Rear Rack
Kickstand
| Size | S | M |
|---|---|---|
| Rider Height | <170 | 170-185 |
| Reach | 390 | 420 |
| Stack | 590 | 640 |
| Bar Width | 600 | 600 |
| BB Drop | 67 | 67 |
| Crank Length | 170 | 170 |
| Fork Length | 408 | 408 |
| Fork Rake | 45 | 45 |
| Front Center | 632 | 680 |
| Head Tube | 165 | 219 |
| Head Tube Angle | 70 | 70 |
| Rear Center | 440 | 440 |
| Seat Angle | 74 | 74 |
| Seat Tube | 450 | 500 |
| Seatpost Length | 350 | 350 |
| Seatpost Offset | 15 | 15 |
| Standover Height | 644 | 653 |
| Stem Angle | ±8 | ±8 |
| Stem Length | 90 | 90 |
| Top Tube | 559 | 603 |
| Trail | 75 | 75 |
| Wheelbase | 1063 | 1111 |
| Frameset |
Frame:
257 Premium Aluminium | Smoothwelded | Staggered Top Tube | Powder Coat Finish | Internal Cable Routing | Flat Mount Disc | 12 x 142mm Thru-Axle
Fork:
257 Premium Aluminium | Fender Mounts | Flat Mount Disc | 12 x 100mm Thru-Axle
|
| Cockpit |
Stem:
BMC RSM 01
Handlebar:
BMC LSB 03
|
| Seat |
Seatpost:
BMC LSP 02
Saddle:
Selle Royal Vivo Women’s
|
| Drivetrain |
Crankset:
FSA Vero Pro
Chainrings:
SHIMANO HG601rings
Cassette:
SHIMANO Deore (CS-M5100)
Cassette Size:
11-42T
Chain:
SHIMANO HG601
Rear Derailleur:
SHIMANO Deore (RD-M5120)
Shifters:
SHIMANO Deore (SL-M5100) | Rapidfire Plus
Gears:
1 x 11
Bottom Bracket:
BSA Threaded Bottom Bracket
|
| Brakes |
Brake Levers / Calipers:
SHIMANO MT200 Levers | BR-U300 Calipers
Rotors:
SHIMANO RT10 Rotors
Rotor Size (F/R):
180 / 180mm
|
| Wheels |
Rims:
PFR300
Hubs (F/R):
CL-712 | RXC-142S
Tires:
Pirelli Angel GT | 37mm
|
| Additional Information |
Tire Clearance:
42mm measured tire
ASTM Classification:
Level 2
System Weight Limit:
120kg
|
| Size — What's my size? | S, M |
|---|
